InRouter302 Compact Industrial LTE 4G Router

InRouter302 - A compact and easy-to-use LTE Cellular Router The InRouter302 (IR302) is a compact M2M router integrating 4G LTE, Wi-Fi, and VPN technologies, it provides easy, reliable, and secure connectivity. Equipped with complete functions, it is applied in various industries and applications. Cost-effectiveness and higher reliability enable you to...
Vendor: InHand Networks
SKU: IR302-FQ78
Availability: In Stock
Product Type: Industrial Routers
$220.00
$220.00
Type: IR302
Description
Description
x

InRouter302 - A compact and easy-to-use LTE Cellular Router

The InRouter302 (IR302) is a compact M2M router integrating 4G LTE, Wi-Fi, and VPN technologies, it provides easy, reliable, and secure connectivity. Equipped with complete functions, it is applied in various industries and applications. Cost-effectiveness and higher reliability enable you to build a digital network with greater ease.

Brand: InHand Networks

InRouter302 Compact Industrial LTE VPN Router

Compact and Rugged Housing Design LTE VPN Router

The InRouter302 LTE router is a compact, reliable, secure and powerful M2M connectivity solution for commercial and industrial scenarios.

-20℃-70℃, IP30 protection level, EMI resistant, lighting resistant

Fully Industrial Design

Fan-less cooling, solid metal shell, strong resistance to vibration and shock, effectively reduce fault rate. The industrial LTE router offers high-quality networking solutions for unattended sites and works well even in harsh environments

industrial LTE and WiFi router

Reliable Network Connection

The backup link provides for network connectivity if the primary link fails. Furthermore, it can automatically failover to a second SIM card with the dual SIM feature.

4G VPN router with strong security protection

Strong Security Protection

The IR302 is designed with comprehensive security protection, including encrypted VPN transmission, firewall protections and multi-level authorization control.

4G VPN router with strong security protection

Free Remote Centralized Management Platform

Device Manager - Join for free
  • Provide remote centralized management of your distributed InHand industrial WiFi routers & gateways
  • Upgrade firmware and update configuration in batch effectively
  • Support grouping management and access control
  • Monitor device status and data usage in real time
  • Easily track your devices in a map view
Device Manager - Remote Management

InConnect Service-Easier to Access to Downstream Devices

IR302 is compatible with InConnect Service, a cloud-based platform engineers can utilize to access the downstream devices through its secure tunnels.

InConnect-Try it now
Remotely Manage IoT Devices by InConnect

Details

Specification
Specification
x
InRouter 302 Hardware Specifications
Hardware Platform
CPU Platform 580MHz
RAM 128MB DDR2
Flash 32MB SPI
Interface
Ethernet Port IR302: 2*10/100Mbps fast Ethernet port, LAN/WAN port 1.5KV network isolation transformer protection
Serial Port 1*RS232
I/O (*Optional) Supports 2*IO (DO or DI can be configured)
Power Supply DC9- -36V, over-current protection,
anti-reverse connection, 2 PIN industrial terminal block
Reset Button Pinhole reset button
SIM Card Dual drawer-type SIM card slots. 2FF SIM
Wi-Fi (Optional) IEEE 802.1 1b/g/n, 150Mbps
Antenna Connector 3G/4G: SMA x 1
Wi-Fi: RP-SMA x 1
Note: North American models (FQ38, FQ33) have 2 x SMA 4G antennas.
Ground Terminal Supports
Mechanical Specs
Dimensions (mm) 90X90x25mm
Weight (g) 240g
Installation Method Panel mounting, rail mounting
Protection Rating IP30
Housing Metal
Cooling Fanless
Power Rate
Working Power 100-120mA@12V
Standby Power 80-90mA@mA@12V
Peak Power 190mA@12.0V
Wi-Fi Transmit Power
Transmit Power 802.11b: 16dBm +/-2dBm (11Mbps)
802.11g: 16dBm +/-2dBm (54Mbps)
802.11n@2.4GHz: 16dBm +/-2dBm (HT20 MCS7)
802.11n@2.4GHz: 16dBm +/-2dBm (HT40 MCS7)
Ambient Environment
Storage Temperature -40 ~ 85℃
Operating Temperature -20 ~ 70℃
Ambient Humidity 5 ~ 95% (non-condensing)
Indicator
LED Power, Status, Cellular, Wi-Fi, cellular Signal
EMC
Static EN61000-4-2, level2
Radiation Electric Field EN61000-4-3, level 2
Pulsed Electric Field EN61000-4-4, level 2
Surge EN61000-4-5,level 2
Conducted Disturbance Immunity EN61000-4-6, level 2
Shock Wave Resistance EN61000-4-12, level 2
Power Frequency Magnetic Field Resistance ; EN61000-4- -8, horizontal I vertical 400A/m (>level 2)
Physical Specs
Shockproof IEC60068-2-27
Vibration Resistance IEC60068-2-6
Free Fall IEC60068-2-32
Certificate
CE, FCC, PTCRB, IC, Verizon, AT&T


InRouter302 Software Specifications
Network Connection
Network Access APN, VPDN, PrivateNetwork
Access Authentication CHAP/PAP
LAN Protocol ARP
WAN Protocol PPP, PPPoE, DHCP
Network Type GSM/GPRS/EDGE, UMTS/HSPA+/EVDO/TD-SCDMA, TDD LTE/
FDD LTE (Please refer to the Ordering Guide for frequencies.)
Network Protocol
IP Application Ping, RouteTrace, DHCP Server, DHCP Relay, DHCP Client, DNS relay, DDNS, Telnet
IP Routing Static routing
NAT Supports network address translation
Security
Network Security Stateful Packet Inspection (SPI), DoS attack defense;
Multicast filter/Ping probe packet, Access Control List (ACL);
Content URL filter, port mapping, virtual IP mapping, IP/MAC binding
Data Security Supports PPTP, L2TP, GRE, IPSEC VPN (IKEv1, IKEv2),
OpenVPN protocols
Supports CA digital certificate
Reliability
Hot Backup VRRP hot backup
Link detection Sends heartbeat packets to detect, auto redials when disconnected
Dual SIM Failover Supports dual SIM failover
Embedded Watchdog Device runs self-detection, auto recovers from malfunctions
WLAN (optional)
Protocol IEEE 802.11b/g/n
Rate Up to 150Mbps
Mode AP, Client and WDS modes
Security Open system, shared key, WPA/WPA2 certification
WEP/TKIP/AES encryption
Transmission
Distance 		80 meters by line of sight (Actual transmission distance depends on environment of the site.)
Network Management
QoS Management Bandwidth limit, IP speed limit
Configuration Telnet, web, ssh, and console
Upgrade Method Web, Device Manager
Logs Local system logs, remote logs, and serial export of logs.
Power down saving of essential logs.
SMS Functions Status query,
configuration, restart
Dial-on-demand Dial-on-demand,
data / SMS activation
Network
Management 		Supports InHand DeviceManager, batch management
SNMP SNMP v1/v2c/v3, support SNMP TRAP
Traffic
Management 		Supports data traffic threshold, traffic statistics and traffic alarm
Alarms System restart alarm, LAN port online/offline alarm, data traffic
alarm, SIM card failure alarm, etc.
Maintenance Tools Ping, route tracking, network speed test
Status Query System status, modem status, network connection status, and routing status
