PSNB - NB-IoT Air/Water Pressure Sensor
PSNB - NB-IoT Air/Water Pressure Sensor
PSNB - NB-IoT Air/Water Pressure Sensor

PSNB - NB-IoT Air/Water Pressure Sensor

Overview The Dragino PS-NB series is a compact NB-IoT pressure sensor designed for monitoring air pressure, water pressure, and liquid levels. It supports threaded and immersion types, multiple pressure ranges, and data transmission via MQTT, UDP, TCP, and more. With BLE setup, OTA updates, and an 8500mAh battery for multi-year...
Vendor: Dragino
SKU: PSLS-5m-1
Availability: In Stock
Product Type: Sensor
$249.00 Excl. GST
$249.00
Type: LS-5m
Description
Description
x

Overview

The Dragino PS-NB series is a compact NB-IoT pressure sensor designed for monitoring air pressure, water pressure, and liquid levels. It supports threaded and immersion types, multiple pressure ranges, and data transmission via MQTT, UDP, TCP, and more. With BLE setup, OTA updates, and an 8500mAh battery for multi-year use, the PS-NB is ideal for long-term IoT deployments. Optional built-in SIM and default server settings make it easy to configure and deploy in smart city, water system, and environmental monitoring applications.

FLG43 Outdoor Edge LoRaWAN Gateway

NBIoT cellular communication

Fully compatible with Australian telcos narrow band network, PS-NB can also upload data via existing cellular network with ultra low power consumption.

FLG8 IP66-rated gateway

Ultra-Low Power & Long Battery Life

Designed for long-term deployment, the sensor is powered by a 2400mAh battery, allowing up to 5 years of operation without frequent maintenance. This energy-efficient design reduces the need for battery replacements, making it cost-effective and reliable.

Cortex A55 1.8GHz CPU, 2GB RAM

BLE Configuration & OTA Updates

The device supports Bluetooth Low Energy (BLE) configuration and over-the-air (OTA) firmware updates, enabling users to set up and upgrade the device remotely. This eliminates the need for manual intervention, simplifying deployment and maintenance.

FLG8 LoRaWAN gateway

Real-Time Pressure Detection

The PS-NB sensor accurately monitors air or water pressure over time and transmits data via NB-IoT networks. This allows for reliable, real-time environmental monitoring in applications such as water systems, tank level tracking, or weather stations. Its durable, low-maintenance design ensures long-term deployment in harsh environments.

Built-in NS and Node-Red

Details

FLG8 Outdoor Edge LoRaWAN Gateway
Specification
Specification
x

Common DC Characteristics
Supply Voltage Built-in Battery , 2.5v ~ 3.6v
Operating Temperature -40 ~ 85°C

NB-IoT Spec
NB-IoT Module BC660K-GL
Support Bands
B1 @H-FDD 2100MHz
B2 @H-FDD 1900MHz
B3 @H-FDD 1800MHz
B4 @H-FDD 2100MHz
B5 @H-FDD 860MHz
B8 @H-FDD 900MHz
B12 @H-FDD 720MHz
B13 @H-FDD 740MHz
B17 @H-FDD 730MHz
B18 @H-FDD 870MHz
B19 @H-FDD 870MHz
B20 @H-FDD 790MHz
B25 @H-FDD 1900MHz
B28 @H-FDD 750MHz
B66 @H-FDD 2000MHz
B70 @H-FDD 2000MHz
B85 @H-FDD 700MHz

Current Input (DC) Measuring
Range 0 ~ 20mA
Resolution 0.001mA
Accuracy 0.02mA
Voltage Input Measuring
Range 0 ~ 30v
Resolution 0.001v
Accuracy 0.02v

Battery
Li/SOCI2 un-chargeable battery
Capacity 8500mAh
Self-Discharge <1% / Year @ 25°C
Max continuously current 130mA
Max boost current 2A, 1 second

Power Consumption
Sleep Mode 10uA @ 3.3v
Max transmit power 350mA@3.3v
Shipping & Return
Shipping & Return
x

Returns Policy

You may return most new, unopened items within 30 days of delivery for a full refund. We'll also pay the return shipping costs if the return is a result of our error (you received an incorrect or defective item, etc.).

You should expect to receive your refund within four weeks of giving your package to the return shipper, however, in many cases you will receive a refund more quickly. This time period includes the transit time for us to receive your return from the shipper (5 to 10 business days), the time it takes us to process your return once we receive it (3 to 5 business days), and the time it takes your bank to process our refund request (5 to 10 business days).

If you need to return an item, simply login to your account, view the order using the "Complete Orders" link under the My Account menu and click the Return Item(s) button. We'll notify you via e-mail of your refund once we've received and processed the returned item.

Shipping

We can ship to virtually any address in the world. Note that there are restrictions on some products, and some products cannot be shipped to international destinations.

When you place an order, we will estimate shipping and delivery dates for you based on the availability of your items and the shipping options you choose. Depending on the shipping provider you choose, shipping date estimates may appear on the shipping quotes page.

Please also note that the shipping rates for many items we sell are weight-based. The weight of any such item can be found on its detail page. To reflect the policies of the shipping companies we use, all weights will be rounded up to the next full pound.

Download
Download
x
  • DataSheet
  • User Manual
  • Firmware
